RHYNO

. RHYNO Twin shaft Mixer

Simem Twin-shaft mixers – a market benchmark thanks to 40 years and thousands of units manufactured to serve the global demand for concrete production.

The next generation of SIMEM mixers has arrived and we welcome the RHYNO!

Simem, known for quality and unquestioned reliability. The RHYNO twin shaft mixer boasts a robust design, user friendly paddle adjustment, and DYNA-FLOW mixing action. This prescribed combination of engineered features extends the lowest maintenance cost per cubic yard, or cubic meter, of concrete produced.

. An Innovative Design

RHYNO twin shaft mixers are lined with stud-mounted high wear resistance liners. RHYNO paddles and arms are bolted to the twin horizontal shafts. The bolt on arm design allows for a various paddle positions to accommodate a variety of mix designs and ease of paddle adjustment.

This method and engineering technology also provides an optimized mixing result.

. Capable for a Range of Capacities

RHYNO twin shaft mixers range from 1 yd3 to 3.5 yd3 of compacted concrete output.

RHYNO twin shaft mixers produce best in class conventional, SCC, RCC, and dry-cast concrete.

. Dyna Flow

THE MOST INNOVATIVE ARMS-PADDLE MIXING SYSTEM ON THE MARKET!

Cutting edge Fluid-Dynamic simulation was used to support the design of paddle profiles and arm connection points. In partnership with a leading Italian University, mixing action was optimized to deliver further mixing advantages for concrete producers, which include:

Improved mix result for small sized aggregate
Reduced mixing time
Reduced wear on paddle connection points
Less intensive mixer cleaning

Specifications

Model	1502	2502	4002	5002	7002
Dry filling capacity m3	1.5	2.5	3.75	5	6.75
Compacted concrete Output - wet concrete m3	1	1.7	2.5	3.33	4.5
Compacted concrete Output - RCC m3	1	1.5	2	3	4
Max aggregate size for standard version mm	80	80	90	90	90
Max aggregate size for HW version mm	-	-	-	150	150
Mixing Motors kW	2x18,5	2x30	2x45	2x55	2x90
